The road sweeper truck is the core product in the intelligent sanitation truck series. Road washing and sweeping truck functions include pavement cleaning, facade washing, low-pressure washing, high-pressure spraying, dust removal and dedusting. The combined design of water tank and dust box can not only spray water for dust removal, but also clean and absorb garbage, reduce dust flying, guarantee clean and tidy road and extend the service life of road.
One-stop Factory in China
Contact: Eva
WhatsApp: +8615927672953 eva@clwag.com
CLICK THIS NUMBER TO GET PRICE
20years of exporting experience, offer whole truck solution and upper body solution
Sanitation+Emergency Rescue Field|7 Integrated Production Line|240.000m³|2 Factories
Product advantages
1. Full suction cleaning, preventing dust backflow and avoiding secondary pollution; easy maintenance and no dust.
2. Cleaning effect is perfect, without leaving a trace, from tens of microns of dust to ordinary stones, leaves and other debris can be effectively removed
3. With high efficiency filtration system
4. Improve cleaning efficiency and reduce cleaning cost: one vacuum cleaner is equivalent to the labor efficiency of more than 30 vacuum cleaners, reducing labor cost.
Basic Info.
|
Transmission Type |
Manual |
|
Emission Standard |
Euro 2-5 |
|
Fuel |
Diesel |
|
Payload |
10-18t |
|
Use |
Burnishing |
|
Cleaning Process |
Cold Water Cleaning |
|
Condition |
New |
|
Sweeping Efficiency |
>95% |
|
After-Sales Service Provided |
Video Technical Support, Field Installation |
|
Clean Width |
3 M |
|
Water Pump Flow |
115 L/Min |
|
Water Pressure |
12 MPa |
|
Clean Speed |
3~20 Km/H |
|
Transport Package |
Nude Packing, Roro Ship, Bulk Ship, Container |
|
Specification |
9350*2480*3160 |
|
Origin |
Suizhou China |
|
HS Code |
8705909990 |
|
Production Capacity |
500 Unit/Month |
Product parameters
|
Overall dimensions [L×W×H (mm) |
7000*2200;2350*2680;2800 |
|
Overall mass (kg) |
7500,7950 |
|
Maximum total mass (kg) |
11995 |
|
Rated mass (kg) |
4365,4300 |
|
Maximum traveling speed (km/h) |
103 |
|
Rated members |
2~3 |
|
Engine Model |
YCY30165-60/D25TCIF1 |
|
Category, Manufacturer |
Dongfeng Motor Co., Ltd. |
|
Engine power (kW) |
121/110 |
|
Wheelbase (mm) |
3800 |
|
Tire |
245/70R19.5;8.25R20 |
|
Brake Form |
Exhaust Brake |
|
Chassis model |
EQ1125SJ8CDC |
|
Dumpster volume (M3) |
5 (stainless steel) |
|
Fresh water tank volume (M3) |
4 (carbon steel for anti-corrosion; optional stainless steel) |
|
Sweeping width (mm) |
2800-3000 |
|
Sweeping speed (km/h) |
3-20 |
|
Cleaning speed (km/h) |
15-20 |
|
Maximum sweeping capacity (M2/h) |
60000 |
|
Sweeping efficiency |
≥98% |
|
Main components of dust reduction system |
Water filter, pipeline, stainless steel spray frame, high-pressure nozzle, etc. |
|
Dust reduction system control form |
Electronic control, one-key operation |
Why choose us?
It has a finished vehicle exhibition area and a fully functional production workshop.
Spraying electrophoresis workshop, testing center and high-end precision equipment.
Diversified high-tech manufacturing enterprises integrating automobile technology R&D, manufacturing and refitting and parts production.
Function Introduction
